Description

Description

"The PRECISIO CS 70 EBG shows its size and power when cutting workpieces up to 70 mm thick, both in the workshop and at assembly sites. Doing the job of two different saws, you can change from cross cutting to rip cutting in just a few hand movements, moving the splinterguard minimises splintering on both sides of the blade. Despite its size, the CS 70 is easy to transport and can be set up instantly thanks to foldaway legs and low weight. All elements of the trimming saw are easily controlled via the multifunction handle. Whilst the smart table groove allows you to easily slide clamps into place to secure your workpiece. It also comes with neat accessory storage and integrated transport rollers for greater mobility.

• Cross cuts up to 320 mm wide
• Rip cuts up to a depth of 70 mm
• Cutting thick material on site or in the workshop
• Cross cuts up to 226 mm wide at 45 degree angle
• Rip cuts up to 680 mm wide with the use of accessories
• CLEANTEC Dust Extraction - Standard adapter (27/36/50 mm) for dust extraction to safeguard the operator and the environment.
• FastFix - Makes changing accessories or consumables for routing, sawing, planing, sanding, drilling and screwdriving tools easier.
• Groove in Saw Table - For fixing and for safeguarding against accidental workpiece slippage, using lever clamps.
• MMC Electronics - Multi Material Control power electronics with adjustable constant speed and temperature monitoring for work with all types of materials.
• Quick Acting Brake - For safe work when planing, sawing and routing.
• Splinterguard - Patented splinterguard for splinter free cuts on both sides when sawing.

Specifications:

• Motor Type: Brushed
• Power Lead Type: Fixed Lead
• Saw Blade Diameter: 225 mm
• Cutting Height 45°: 0° - 48°
• Cutting Height 90°: 0° - 70°
• Inclination Angle: 0 (-2)° - 45 (+47)
• Cutting Path: 320 mm
• Table Dimensions: 1,260 mm x 910 mm
• Table Height - Legs Folded Away: 375 mm
• Table Height - Legs Unfolded: 900 mm
• Dust Extraction Connection Diameter: 27 mm / 36 mm
• Tool Weight: 66 kg

Includes:

• 1 x CS 70 EBG PRECISIO Trimming Saw
• 1 x Sliding Table for Table Saw 650 mm 490312
• 1 x Side Table for Table Saw 411 mm 488060
• 1 x Rear Table for Table Saw 580 mm 488061
• 1 x Universal Saw Blade HW W32 488288
• 1 x Mitre Guide 574797
• 1 x Foldaway Legs
• 3 x Splinterguards 490340
• 1 x Dust Extraction Hose Set with Y Piece 488292
• 1 x Push Stick
• 1 x Accessories holder
• 1 x Support with transport roller
• 1 x Tool Manual
